Katz Heater Plumbing
Topic Started: Jan 11 2011, 11:18 AM (2,813 Views)
Abraham
New Member
[ *  * ]
My engine doesn't high idle after heating with the Katz, so I'll call it good and move on.
Offline Profile Quote Post Goto Top

Tofuball
Member Avatar
Strange Mechanic

All the metro ECUs that I messed with run CRAZY RICH when cold.

Fuel cut is disabled, closed loop is disabled, and you're stuck at about 0.45gph whether you idle high or not.
Accelerate and it just DUMPS the gas in.

To top it off our engines cool off really fast too. It would be good to seal off the engine bay somehow, only allowing air into the radiator.
Offline Profile Quote Post Goto Top

zukiman
Fresh Fish
[ * ]
I installed the heater and had to run to town everything seemed fine. when I came out of the store (car still running at an idle for about 10 min) it was blowing cold air and the engine temp was normal. I then opened the hood and the hose from the thermostat housing was hotish to the heater core and the hose to the tank heater were cool. this made me think that the tank heater is plugged in backwards. So I was looking for answers before doing anything stupid. so i didn't even plug it in yet.
Offline Profile Quote Post Goto Top

Bad Bent
Member Avatar
Facetious Educated Donkey

OK... I need pictures, please. That and a Katz part number.

Mine 1991 looks like this:
Posted Image

"Cold" coolant (blue line) going in the bottom/side and hot coming out the top. The 1000W heater is mounted vertically beside/below the battery on the right.
Offline Profile Quote Post Goto Top

zukiman
Fresh Fish
[ * ]
changed the lines around and works fine. i guess i should have looked at it better. Plugging it in tonight to see how it preheats.
I am inline with the output of the heater core line.
Offline Profile Quote Post Goto Top

Bad Bent
Member Avatar
Facetious Educated Donkey

:thumb :thumb

I plug my 1000 watt heater in for 20-30 minutes and it heats most hoses. Does not show on the temp. gauge but it only takes 2 miles to get into the "optimal" operating zone.
Edited by Bad Bent, Feb 21 2012, 10:21 PM.
Offline Profile Quote Post Goto Top
