Here it is!; What to call it? It will be TED
Topic Started: Aug 21 2014, 12:25 PM (13,304 Views)
David95237


You are changing the valve stem seals also?
Offline Profile Quote Post Goto Top

freegeo
Member Avatar


David95237
Jul 1 2015, 01:52 PM
You are changing the valve stem seals also?
Yes I am. I got a full gasket kit and plan on using almost everything in it.
Offline Profile Quote Post Goto Top

freegeo
Member Avatar


snowfish
Jul 1 2015, 01:37 PM
Quote:

Got the valves all wire brushed off.

You are replacing at least the exhaust valves, right? :news Cheap insurance. ^o) New ones lap some much nicer too. :thumb
Looking forward to hearing this baby purr! :popcorn
You know snowfish after I read this I looked at the exhaust valves and there is a little pitting on the sealing surface.

Posted Image

It is either get these ground which would probalby cost about as much as new ones. I need new head bolts anyway. I'll take a look on rockauto and see what they cost . If I remember right it wasn't that much for my last head.

The intake valves looked really good.
Edited by freegeo, Jul 1 2015, 11:23 PM.
Offline Profile Quote Post Goto Top

freegeo
Member Avatar


I took your advice snowfish and ordered new exhaust valves along with new head bolts. Should have them monday so won't get it completely put back together this weekend. That's okay it won't take very long to lap the valves and put them in.
Offline Profile Quote Post Goto Top

freegeo
Member Avatar


My starter too a :shit on me last week so I looked for a new one. Found a NOS one on ebay. Got it today and it looks great. Gonna go and get it on before it starts raining.

New one. :banana :bacondance

Posted Image
Edited by freegeo, Jul 3 2015, 04:49 PM.
Offline Profile Quote Post Goto Top

freegeo
Member Avatar


I got my new starter installed and and went to start it and got absolutely nothing. Well :shit . First I thought maybe the starter could be bad, so I got a lengthy piece of 10 gauge wire and added a connector to the end of it. Hooked the connector to the solenoid and touched the other end of the wire to the positive of the battery. Starter cranked right up.

Time for the FSM to see what has happened. Looked up the stater and charging section and go to the chart # 2 Engine does not crank and solenoid does not click.

# 1 check for voltage at the wire to the solenoid. No voltage present.

# 2 check for voltage at the clutch position switch. Had voltage to it but not coming out of it. Got my flashlight to see under the dash better and realized the wire had come off the switch. Re attached it and the car started right up. Better than before.

Lapped my intake valves tonight and used a stone to flatten the head gasket surface. Still have to check it with a straight edge but it looks like it will be ok.


Wire brushed the oil pan to get the surface rust and loose paint off of it. Going to run it through the ultrasonic cleaner once more to get the silicone and rust off of it before primer and paint.

I'll try and get some pics up of the progress.
Offline Profile Quote Post Goto Top

freegeo
Member Avatar


Got my new exhaust valves monday and had some time the last few days to to get them lapped in.

Only need to wire brush the outside of the head and get the old valve stem seals off. Put the new seals in and assemble the valves and springs.

Bosses at work said today that we should have the weekend off so I should have time to work on the engine again. Hopefully I can get the oil pan primed and painted tomorrow if it doesn't rain.

Posted Image

Posted Image
Offline Profile Quote Post Goto Top

idmetro
Member Avatar


Looks like it is coming along, here's hoping time and weather cooperate so you continue the progress.
Offline Profile Quote Post Goto Top

ZXTjato
Member Avatar
bass heads

your starter issue is how i got my red car so cheap, the previous owner did not wamt to spend $$$ to fix starter issues and my dad fixed the issue by just plugging the wire on.
Offline Profile Quote Post Goto Top

freegeo
Member Avatar


ZXTjato
Jul 9 2015, 08:46 AM
your starter issue is how i got my red car so cheap, the previous owner did not wamt to spend $$$ to fix starter issues and my dad fixed the issue by just plugging the wire on.
Your right. Sometimes people will get rid of something due to something simple going wrong and not wanting to mess with it.
Offline Profile Quote Post Goto Top

snowfish
Member Avatar
Basic GearHead

Now that's looking great! :thumb If you haven't already, good idea to make sure the oil gallerys are clean, clean, clean. :gamerz Easy to pull the plugs and rinse/blast everything out. :cheers
Offline Profile Quote Post Goto Top

freegeo
Member Avatar


snowfish
Jul 9 2015, 10:06 AM
Now that's looking great! :thumb If you haven't already, good idea to make sure the oil gallerys are clean, clean, clean. :gamerz Easy to pull the plugs and rinse/blast everything out. :cheers
I have run the head through the ultrasonic cleaner a number of times. I keep that in mind before I put the head back on.
Offline Profile Quote Post Goto Top

freegeo
Member Avatar


It has been raining like everyday. Did get a chance to wire brush the oil pan one more time and get some rust converter primer on it.

Posted Image

Couple coats of paint and ended up with this.

Posted Image

It is not perfect but neither is the rest of the engine. Just got to let it dry a few days to harden up before putting it on the block.

I have the weekend off and no grand kids to mess with. Next week I work monday and tuesday and have the rest of the week off. Hopefully if things work out I maybe able to start swapping engines.
Offline Profile Quote Post Goto Top

Stubby79
Member Avatar


What is this "rain" that you speak of?!
Online Profile Quote Post Goto Top

freegeo
Member Avatar


Stubby79
Jul 10 2015, 01:03 PM
What is this "rain" that you speak of?!
The watery substance that comes from above.
Offline Profile Quote Post Goto Top
